Calliope Studio

Calliope Studio is a web-based user interface for the Calliope energy system modelling framework. It lets you define, edit, validate, run, and analyse Calliope models, all in a single tool. It runs in a browser directly on your computer.

Installation

With uv:

# One-time setup for uv on macOS and Linux
curl -LsSf https://astral.sh/uv/install.sh | sh
# One-time setup for uv on Windows
#   powershell -c "irm https://astral.sh/uv/install.ps1 | iex"

uv tool install calliope-studio

Or with conda/mamba:

conda create -n calliope-studio -c conda-forge calliope-studio
conda activate calliope-studio

Then:

calliope-studio my-model      # a model folder containing model.yaml or a solved results .nc
calliope-studio               # no argument opens Calliope Studio with a model picker

To quit Calliope Studio, close its terminal window or press Ctrl+C inside it.

Development builds

To install a development build based on the latest main branch commit:

uv tool install --reinstall --prerelease allow \
  --find-links https://github.com/sjpfenninger/calliope-studio/releases/expanded_assets/dev \
  calliope-studio

The same command updates an existing install to the newest development build. To go back to the stable (released) version:

uv tool install --reinstall calliope-studio

FAQ

• Why does "Run" fail with a solver error? Calliope needs a solver to run a model. Calliope 0.7 bundles the HiGHS solver, but some models may refer to other solvers such as CBC or Gurobi. Refer to the Calliope documentation for the different solver options.
• Why is the list of models wrong or outdated? The list of models you have opened lives in a small registry file, separate from the models themselves. Its location is reported as registry_path by http://127.0.0.1:8000/api/health while Calliope Studio is running. Deleting it resets the list without actually touching any of your models.
• Where are model results stored? When running a model from inside Calliope Studio, results are saved in a calliope-studio/ folder next to the model.yaml file. This folder is created automatically when running a model for the first time and comes with its own .gitignore file.

Development

Requires pixi. Try pixi task list to see all the available development tasks.

pixi run serve      # API on port 8000 with auto-reload
pixi run web-dev    # Vite dev server, proxying /api to port 8000

serve opens ./example-model, scaffolding it from Calliope's national_scale template on first use.

The frontend tests run from web/:

cd web
pnpm test

Pixi is configured with a gurobi environment to test with Gurobi (needs a license):

pixi run -e gurobi calliope-studio my-model   # Gurobi available as a solver

Release

Pushing a v* tag builds the wheel and sdist and publishes them:

git tag v0.2.0 && git push --tags

A release tag with exactly three numeric components (v0.2.0) goes to PyPI. Anything else (e.g. v0.2.0rc1 or a typo) goes to TestPyPI instead.

On release, the conda-forge autotick bot should open a pull request on the feedstock.

Architecture

The frontend is a Vue 3 single-page TypeScript app served by a FastAPI backend.

The backend consists of four Python packages with a one-way import rule: server may import the others, while they import neither server nor each other:

• server: FastAPI app and HTTP routes
• modeldef: YAML and CSV model definitions on disk
• runs: Builds and solves models in a separate process
• results: Reads .nc files and streams them as Apache Arrow batches for charts and tables

License

AGPL-3.0-or-later. See LICENSE.
